| A. FF - 350 DESCRIPTIONS FOR EACH PORTIONS |
|
|
| ( FF - 350 各部功能說明 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Fluid Outlet (流體出口 ) or Plug ( 塞住不用 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Fluid Outlet |
|
|
|
|
Fluid Inlet ( 流體入口 ) |
| ( 流體出口 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Combine ( 逆時鐘方向組合 ) |
|
|
|
|
|
|
Disintegrate ( 順時鐘方向分解 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Fluid Drain Valve |
|
|
|
|
|
|
| ( 流體排放球閥 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Fluid Drain ( 流體排放口 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| B. SPECIFICATIONS ( 規格 ) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Inlet Size ( 入口口徑 ) |
FF - 350 : 3/4" PT |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Outlet Size ( 出口口徑 ) |
FF - 350 : 3/8" PT * 3 |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Drain Size ( 排放口 ) : 1/4" PT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Max Working Pressure ( 最高使用壓力 ) |
FF - 350 : 5000PSI |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Area / sq. ( 過濾面積 ) : 116c㎡ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Max Delivery ( ****處理流量 ) : 1 GPM ( 4 LPM ) |
|
|
|
|
|
|
|
|
|
|
|
|
| Strainer ( 濾網 ) : 60mesh、100mesh、200mesh SST ( 60、100、200目白鐵網 ) |
|
|
|
|
|
|
|
|
|
| Wetted Parts ( 接液材質 ) |
FF - 350 : Steel ( 鐵鍍鉻 ) |
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Temperature Conditions ( 適用溫度範圍 ) : 40 - 212F ( 4.4 - 100℃ ) |
|
